Home > Products > ISUZU > Pickup Truck

Isuzu TAGA Pickup Truck With Double Cab

Customizable

Fuel Type: Diesel/Gasoline

Payload Capacity: 485KG - 800KG

Emission Standard: Euro 6

Drive Wheel: 4×2, 4×4

Engine Power: 143PS, 230PS

Parameter:

Isuzu TAGA Pickup Truck
NO.	SPECIFICATION	PARAMETER
		4×2								4×4
1	Vehicle Model	QL1030BZHW	QL1030BZHW2	QL1030BZGW	QL1030BZGW2	QL1030AGGW	QL1030AGGW1	QL1030AGHW	QL1030AGHW1	QL1030CZHW	QL1030CZHW2	QL1030CZGW	QL1030CZGW2	QL1030CGHW	QL1030CGHW1	QL1030CGGW	QL1030CGGW1
2	Fuel Type	Diesel				Gasoline				Diesel				Gasoline
3	GVW(kg)	2875	3190	2845	3160	2710	3025	2720	3035	2980	3295	2950	3265	2820	3135	2811	3126
4	Curb Weight(kg)	2065	2065	2035	2035	1900	1900	1910	1910	2170	2170	2140	2140	2010	2010	2001	2001
5	Axle Loads(kg)	1290/1585	1275/1915	1280/1565	1250/1910	1235/1475	1200/1825	1240/1480	1205/1830	1360/1620	1350/1945	1335/1615	1325/1940	1290/1530	1290/1845	1286/1525	1286/1840
6	Cabin	2+3
7	Overall Dimension(mm)	5660,5700,5692×1885, 1955,1877×1830,1805		5350,5382,5390×1885, 1877,1955×1830,1805		5350,5382,5390×1885, 1877,1955×1830,1805		5660,5700,5692×1885, 1955,1877×1830,1805		5660,5700,5692×1885, 1955,1877×1830,1805		5350,5382,5390×1885, 1877,1955×1830,1805		5660,5700,5692×1885, 1955,1877×1830,1805		5350,5382,5390×1885, 1877,1955×1830,1805
8	Box Dimension(mm)	1800×1540×480		1485×1540×480		1485×1540×480		1800×1540×480		1800×1540×480		1485×1540×480		1800×1540×480		1485×1540×480
9	Wheelbase(mm)	3406		3096		3096		3406		3406		3096		3406		3096
10	Engine	4KH1CT6H1				CE18				4KH1CT6H1				CE18
11	Engine Output (kW(PS))	105kW(143PS)				170kW(230PS)				105kW(143PS)				170kW(230PS)
12	Displacement(L)	2.999				1.765				2.999				1.765
13	Emission Standard	Euro 6
14	Braking Mode	Oil Brake
15	Max Speed(km/h)	140				150				140				150
16	Front/Rear Overhang(mm)	945/1309,977/1309,985/1309
17	Tire Model	245/70R17LT 10PR
