| Ankai Mini Electric Coach | ||
| NO. | SPECIFICATION | PARAMETER |
| 1 | Model | HFF6710N7EV21 (N71E) |
| 2 | Body Structure | Full-integral |
| 3 | Standard Seating Capacity | 18+1 (10–23 optional) |
| 4 | Energy Type | Electric |
| 5 | Overall Dimension (mm) | 7145×2080×2645,2725,2810 |
| 6 | Gross Vehicle Weight (kg) | 8900 |
| 7 | Curb Weight (kg) | 5500,5800 |
| 8 | Luggage Compartment Volume (m³) | 0.42 |
| 9 | Wheelbase (mm) | 3935 |
| 10 | Wheel Track (Front/Rear) (mm) | 1740/1540 |
| 11 | Front/Rear Overhang (mm) | 1150/2060 |
| 12 | Maximum Speed (km/h) | 100 |
| 13 | Driving Range (km) | 480 |
| 14 | Battery Brand | CATL (Contemporary Amperex Technology Limited) |
| 15 | Battery Capacity (kWh) | 155.33 |
| 16 | Motor Power (kW) | 160 |
| 17 | Suspension System | Full air suspension, 2 front airbags and 4 rear airbags |
| 18 | Service Brake / Parking Brake | Dual-Circuit Pneumatic Brake, Front & Rear Disc Brakes / Spring Energy Storage Brake |
| 19 | Tire Specification | 215/75R17.5 |
| 20 | Air Conditioning | Built-in air conditioning (heating & cooling) |
| 21 | Driver Seat | Adjustable forward/backward seat with 3-point safety belt |
| 22 | Passenger Seats | faux leather seats (adjustable, non-removable) with safety belts |
*More parameters can be customised, please contact us for more information.
