| Qingling Isuzu 100P Dump Truck | ||||
| NO. | SPECIFICATION | PARAMETER | ||
| 4×2 | ||||
| 1 | Vehicle Model | QL3041MVFW | QL3070BUHW | QL3070BUHW |
| 2 | GVW(kg) | 4495 | 7010 | 7010 |
| 3 | Curb Weight(kg) | 2675 | 3185 | 3185 |
| 4 | Axle Loads(kg) | 1860/2635 | 2300/4710 | 2300/4710 |
| 5 | Cabin | 2+3 | 2+3 | 2+3 |
| 6 | Overall Dimension(mm) | 4995×1880×2375 | 5900×1945×2375 | 5900×1945,1880×2375 |
| 7 | Wheelbase(mm) | 2795 | 3360 | 3360 |
| 8 | Engine | 4KK1N6SD | 4KB1-TCG60 | 4KH1CN6LB |
| 9 | Engine Output (kW(PS)) | 97kW(132PS) | 96kW(130PS) | 88kW(120PS) |
| 10 | Displacement(L) | 2.499 | 2.499 | 2.999 |
| 11 | Emission Standard | Euro 6 | Euro 6 | Euro 6 |
| 12 | Braking Mode | Oil Brake/Air Brake | ||
| 13 | Max Speed(km/h) | 115 | 115 | 95 |
| 14 | Front/Rear Overhang(mm) | 1015/1185,1015/1180 | 1015/1525 | 1015/1525 |
| 15 | Tire Model | 7.00R16LT 8PR/7.00R16LT 14PR | 7.00R16LT 14PR | 7.00R16LT 14PR |
*More parameters can be customised, please contact us for more information.
