| Genlyon C6P 8×4 Battery Electric Multi-configuration Dump Truck (BEV) | |||||||||
| NO. | SPECIFICATION | PARAMETER | |||||||
| 1 | Vehicle Model |
CQ3311BEV HV56U |
CQ3311BEV HU56V |
CQ3311BEV HV56U |
CQ3311BEV HU56V |
CQ3311BEV HV56U |
CQ3311BEV HU56V |
CQ3311BEV HV56U |
CQ3311BEV HU56V |
| 2 | Series | Genlyon C6P | |||||||
| 3 | Drive Wheel | 8×4 | |||||||
| 4 | Load Version | G2 | |||||||
| 5 | Energy Type | Battery Electric (BEV) | |||||||
| 6 | Cabin | Flat Roof Standard Cab | |||||||
| 7 | Battery Power (kW) | 335/530 | |||||||
| 8 | Traction Battery | 400kWh | 600kWh | 400kWh | 600kWh | 400kWh | 600kWh | 400kWh | 600kWh |
| 9 | Battery Layout | Behind-cab mounted | |||||||
| 10 | Transmission | J4S240+QH708 | |||||||
| 11 | Front Axle | HY6.5T | |||||||
| 12 | Drive Axle | HY300（H）-5.73 | |||||||
| 13 | Wheelbase (mm) | 1800+3200+1400 | 1800+3500+1400 | 1800+3800+1400 | 1800+4200+1400 | ||||
| 14 | Frame (mm) | 980_865/305×7+4 | |||||||
| 15 | Suspension | 9/9/12(T40) | |||||||
| 16 | Tire Model | 11.00R20 PR18 Mixed Tread Tire | |||||||
| 17 | Fifth Wheel | / | |||||||
| 18 | GVWR (kg) | / | |||||||
| 19 | Body Size (mm) |
5600,5800,6000,6200,6400,6500,6600,6800,7000×2300,2350,2400× 1500,1450,1400,1350,1300,1250,1200,1150,1100,1050,1000,950,900,850,800 |
|||||||
*More parameters can be customised, please contact us for more information.
