| Genlyon C6P 8×4 Diesel Multi-configuration Dump Truck | ||||
| NO. | SPECIFICATION | PARAMETER | ||
| 1 | Vehicle Model | CQ3317HV09306 | CQ3317HV11366 | CQ3317HV11386 |
| 2 | Series | Genlyon C6P | ||
| 3 | Drive Wheel | 8×4 | ||
| 4 | Load Version | G3 | ||
| 5 | Fuel Type | Diesel | ||
| 6 | Cabin | Flat Roof Standard Cab | ||
| 7 | Engine | C9390 | C11460 | C11460 |
| 8 | Transmission | 12JSD180T AL | 12JSDX220TB AL | 12JSDX220TB AL |
| 9 | Retarder | × | ||
| 10 | Front Axle | 7.5T | ||
| 11 | Drive Axle | HY300（M）-5.262 | ||
| 12 | Wheelbase (mm) | 2000+3000+1400 | 2000+3600+1400 | 2000+3800+1400 |
| 13 | Frame (mm) | 980_865/305×8+4 | ||
| 14 | Suspension | 8/12/12(T40) | 9/12/12(T55) | 9/12/12(T55) |
| 15 | Tire Model | 12.00R20 PR18 mixed tread | ||
| 16 | Fuel Tank Capacity (L) | 400 | ||
| 17 | Fifth Wheel | / | ||
| 18 | GVWR (kg) | / | ||
| 19 | Body Size (mm) |
6000,6200,6500,6600,6700,6800,7000×2350,2300 ×800,900,1000,1100,1150,1200,1300,1400,1500 |
6800,7000,7200,7400,7600,7800× 2350,2300×1150,1200,1300,1500 |
7200,7400,7600,7800,8000,8200× 2350,2300×1150,1200,1300,1500,300 |
*More parameters can be customised, please contact us for more information.
