| Genlyon C6P 6×4 Diesel Heavy-Duty Dump Truck | |||||
| NO. | SPECIFICATION | PARAMETER | |||
| 1 | Vehicle Model | CQ3257HV11424 | CQ3257HV13424 | CQ3257HV13444 | CQ3257HV13474 |
| 2 | Series | Genlyon C6P | |||
| 3 | Drive Wheel | 6×4 | |||
| 4 | Load Version | K2 | |||
| 5 | Fuel Type | Diesel | |||
| 6 | Cabin | Flat Roof Standard Cab | |||
| 7 | Engine | C11460 | C13560 | C13560 | C13560 |
| 8 | Transmission | 12JSDX220TB AL | 13JSDX260T AL | 13JSDX260T AL | 13JSDX260T AL |
| 9 | Retarder | × | |||
| 10 | Front Axle | 7.5T | |||
| 11 | Drive Axle | HY320-5.214 | |||
| 12 | Wheelbase (mm) | 4200+1400 | 4200+1400 | 4400+1400 | 4400+1400 |
| 13 | Frame (mm) | 980_865/317×8+8 | |||
| 14 | Suspension | 9/12(T55) | |||
| 15 | Tire Model | 12.00R20 PR16 Heavy-Duty Mixed Tread Tire | |||
| 16 | Fuel Tank Capacity (L) | 400 | |||
| 17 | Fifth Wheel | / | |||
| 18 | GVWR (kg) | / | |||
| 19 | Body Size (mm) |
6000,6200,6400×2300,2350,2400× 800,900,1000,1150,1200,1300,1400,1500 |
6200,6300,6400,6500,6600×2300,2350,2400× 800,900,1000,1100,1150,1200,1300,1400,1500 |
||
*More parameters can be customised, please contact us for more information.
