| Genhoo H6 8×4 Diesel Multi-configuration Dump Truck | |||||
| NO. | SPECIFICATION | PARAMETER | |||
| 1 | Vehicle Model | CQ3317EV09256 | CQ3317EV09256 | CQ3317EV09306 | CQ3317EV09306 |
| 2 | Series | Genhoo H6 | |||
| 3 | Drive Wheel | 8×4 | |||
| 4 | Load Version | G2 | G3 | G2 | G3 |
| 5 | Fuel Type | Diesel | |||
| 6 | Cabin | Flat Roof Standard Cab | |||
| 7 | Engine | C9390 | |||
| 8 | Transmission | 12JSD160T AL | |||
| 9 | Retarder | × | |||
| 10 | Front Axle | HY5.5T | 7.5T | HY5.5T | 7.5T |
| 11 | Drive Axle | HY300（HQ）-5.13 | HY300（M）-5.214 | HY300（HQ）-5.13 | HY300（M）-5.214 |
| 12 | Wheelbase (mm) | 2000+2500+1400 | 2000+2500+1400 | 2000+3000+1400 | 2000+3000+1400 |
| 13 | Frame (mm) | 980_865/280×8+4 | 980_865/305×8+4 | 980_865/280×8+4 | 980_865/305×8+4 |
| 14 | Suspension | 8/12/12(T40) | |||
| 15 | Tire Model | 11.00R20 PR18 mixed tread | |||
| 16 | Fuel Tank Capacity (L) | 300 | |||
| 17 | Fifth Wheel | / | |||
| 18 | GVWR (kg) | / | |||
| 19 | Body Size (mm) |
5600,5800,6000,6200,6400×2350,2300×800, 900,1000,1100,1150,1200,1300,1400,1500,950 |
6000,6200,6500,6600,6800,7000,6700× 2350,2300×900,1150,1200,1300,1500 |
||
*More parameters can be customised, please contact us for more information.
